Creality Creator PWR: обзор, плюсы и минусы

Creality Creator PWR

Product: Creality Creator PWR, distributor item 4008030122

Controller: ESP8684-MINI-1-H4 Wi-Fi module, 2.4 GHz 802.11 b/g/n (2412–2462 MHz)

Mains input: 100–240 V AC, 50/60 Hz

Switched output: 100–240 V AC, 50/60 Hz

Communication input: 5 V, Type-C, input only

Цена не указана

Новые

Б/у, восстановленные, вскрытые

eBay (used) eBay: used, open-box, refurbishedОткрыть: eBay (used)

Магазины идут в фиксированном порядке — не по цене и не по комиссии. Цены — это снимки на момент проверки. Уточняйте актуальную цену в магазине.

Кратко

Wi-Fi AC power controller and energy meter for compatible 3D printers, sold by Creality and built on BIQU’s Panda PWR hardware.

Сильные стороны

Adds wireless on/off, energy monitoring and timed or print-completion shutdown to a compatible printer without a separate screen.
Local web dashboard runs in a browser, with documented factory reset and firmware recovery tools.
Real-time voltage, current, watts and accumulated energy can expose a printer’s baseline draw.
Two 5 V USB ports can power low-current accessories, with USB1 following the printer’s LED.
Listed around $39 at Creality’s US store, below many dedicated printer power modules.

Слабые стороны

No independent instrumented test, teardown or exact-model owner discussion was found.
Only 2.4 GHz Wi-Fi is documented; setup depends on local network access to port 4408.
One published owner review complains about the interface and launch readiness.
Warranty terms differ by seller: up to 12 months at Creality, 180 days at BIQU.
Shutdown after print completion cuts mains power, which may interrupt the printer’s cool-down fans.

Проверенные характеристики

Product	Creality Creator PWR, distributor item 4008030122; BIQU and BigTreeTech sell the same hardware as “Panda PWR” (model PANDAPWRV1).
Function	Wi-Fi AC power management with wireless on/off, real-time voltage, current, power and energy monitoring, countdown and print-completion shutdown, plus two 5 V USB-A ports.
Controller	ESP8684-MINI-1-H4 Wi-Fi module, 2.4 GHz 802.11 b/g/n (2412–2462 MHz); BTT documentation lists 272 KB RAM and 4 MB flash, not independently verified.
Mains input	100–240 V AC, 50/60 Hz.
Switched output	100–240 V AC, 50/60 Hz; BIQU’s page states 9 A, the FCC-filed manual states 3 A.
Communication input	5 V, Type-C, input only.
USB	two ports, 5 V at up to 1.5 A each (USB1 controllable, USB2 always on).
Wi-Fi certification	FCC ID 2BAS6-PANDAPWRV1, grantee Shenzhen BIQU Innovation Technology Co., Ltd.; conducted output 0.01982 W; 20 cm separation from persons required.
Dimensions	141.66 × 65.66 × 34.5 mm; cable length 500 mm.
Box contents (Creality)	Creator PWR ×1, packaging box ×1, BTT Duck ×1, sticker ×2.
Box contents (BIQU)	Panda PWR ×1, USB-C charging cable ×1, package box ×1, BTT Duck ×1.
Compatibility	Creality lists K2 Series, K1 Series, Ender-3 V3, Ender-3 V3 Plus, Creality Hi and other Klipper printers; BIQU lists additional C14-inlet machines.
Warranty	Creality states “up to 12-month” warranty and 14-day return/refund; BIQU states 180 days.

Полные заметки исследования и источники

Электрические параметры и вопрос 3 А

The FCC report for the radio family lists 100–240 V AC input and 100–240 V AC switched output at 3 A, which is 360 VA at 120 V. Creality markets the unit for K1 and K2 series printers, while its own K1 Max is rated 1,000 W and the K1 350 W. The FCC report states those variants share radio and circuit hardware, but it is not a substitute for checking the unit’s own label. Ask Creality or BIQU for written confirmation of the approved load for the exact unit before using it with a high-power printer; do not rewire or experiment.

Настройка и повседневное использование

Initial setup uses a temporary access point and a local web page, usually at 192.168.254.1, then joins a 2.4 GHz network; the printer is linked by IP address and port 4408. Change the default access-point password after setup and keep the dashboard off the public internet. The device supports countdown timers, one-shot shutdown after a completed print, USB1 control and high/low power cutoffs. USB2 stays on at all times. Job-aware shutdown depends on correct network and host configuration; manual button control remains available.

Расходы на эксплуатцию, запчасти и гарантия

No scheduled consumables or subscription are documented. The main ownership costs are the unit itself and, if damaged, a correctly specified replacement AC cord; no verified replacement-cord SKU or price was found. Creality advertises a 14-day return window and up to 12 months of warranty, while BIQU advertises 180 days; confirm the exact term for the purchased unit in writing. Support contacts include cs@creality.com and service001@biqu3d.com, and the FCC-filed manual lists service005@biqu3d.com.

Стоит ли покупать?

October 2026 channel listings ranged from $35.49 to $62.90: Creality’s store at $39.43 against a $49.29 compare-at price, a variant tile at $35.49, BIQU at $38.99 against $49.99 regular, Newegg at $52.97 with import shipping, and the K2 accessory hub at $53.36. At or below $35 delivered it is reasonable only if the buyer specifically needs the documented Klipper completion workflow. Above $45–$55 a Shelly Plug US Gen4 at $24.99 offers 15 A / 1,800 W switching and a three-year warranty, though it does not provide the printer-specific completion logic. Do not buy if the AC rating cannot be reconciled with the printer’s nameplate, regardless of price.

О какой модели речь

This page covers the Creality Creator PWR, distributor item 4008030122, a Wi-Fi AC power controller for compatible printers. The same hardware is sold by BIQU and BigTreeTech as “Panda PWR” (FCC ID 2BAS6-PANDAPWRV1, model PANDAPWRV1). The Amazon listing for this product is ASIN B0G57PD7CD. Creality’s store page does not publish an FCC ID; the FCC grant is under BIQU’s name.
